SOLANO TOP HVAC & EVAP

Compact, powerful and easy to mount rooftop air-conditioning or heating and air-conditioning unit, ensuring optimal comfort for operator in cab.

Ideal for engins with limited space in cab and/or limited space in the engine compartment, the SOLANO TOP HVAC EVAP is easy to mount on the roof via 4 M6 holes.

Also exists in electric EHVAC version.

Available in 12V and 24V, the HVAC version offers a cooling capacity of 6,75kW and a heating capacity of 5,6kW for a nominal air flow of 445m3/h. The AC version, also available in 12V and 24V, offers a cooling capacity of 6,8kW and a nominal air flow of 465 m3/h for an electric power of 200W.

For a complete solution, associate the SOLANO TOP to :

Technical summary

  • 2 versions: air conditioning or heating & air conditioning unit
  • 3 speed ventilation
  • Voltage : 12V or 24V
  • HVAC version : Ø16mm water hose diameter
  • Including anti-freezing thermostat
  • Clamping on the roof with 4 M6 holes
  • Expansion valve O-ring connection
  • Supplied with electrical connectors
Information request
See product sheet

Choose another version

Technical data
Type Voltage Electrical power Weight Nominal air flow Heating capacity Cooling capacity
HVAC 12/24 V 200 W 10 kg 445m3
/h
5,6 kW 6,75 kW
EVAP 12/24 V 200 W 10 kg 465m3
/h
- 6,8 kW
